Description

Technical Specs

• Voltage: 100-277V AC 50/60Hz
• Wattage: 50W/80W/100W/150W
• Power Factor: 0.9
• THD20%
• Efficacy: 130LM/W
• AL1060 Aluminum Housing, Outdoor Powder Coating
• Twist-Lock Zhaga Socket Pre-Installed. See Motion
• Sensor Accessories.
• 6š¬ššš¬šž SJTW 18,3 AWG Power Cable
• 6š¬ššš¬šž SJTW Dimming Cable
• Aluminum LED board: High Conductive, Waterproof, Aging Resistance, Salt resistance
• Programmable Bi-Level Motion Sensor Emergency Backup Options
• Operating Temperature: -40F~104F
• IP Rating: IP66, Suitable for Wet Locations
• 7-Year Warranty
• Multi CCT and Power: Selectable Switch Inside Of The Fixture
• Dimmable: 0~10V Dimming
• Lens: High Light Transmittance PC, anti-UV and Fire Resistant
• LED: Lumileds 2835
• Total Lumens: 13000LM-19500LM Max.
• Color Temperature: 3000K/4000K/5000K
• Color Rendering Index: 70
• Beam Angle: Type V (150 X 150)
• Lifespan: 70000 Hrs.

Applications

• Ideal for Gardens, Amusement Parks, Residential Quarters, Industrial Parks, and Pedestrian Streets.
