Description

Technical Specs

• Voltage: 100-277V AC 50/60Hz
• Wattage: 50W/80W/100W
• Power Factor: 0.9
• THD20%
• Efficacy: 140LM/W
• AL1060 Aluminum Housing, Outdoor Powder Coating
• Photocell Included (with Disconnect Switch) Twist-Lock Zhaga Socket Pre-Installed. See Motion
• Sensor Accessories.
• 6′ SJTW 18,3 AWG Power Cable
• 6′ SJTW Dimming Cable
• Aluminum LED Board: High Conductive, Waterproof, Aging Resistance, Salt Resistance
• Operating Temperature: -40F~104F
• IP Rating: IP66, Suitable for Wet Locations
• 7-Year Warranty
• Multi CCT and Power: Selectable Switch Inside of the Fixture
• Dimmable: 0~10V Dimming
• Lens: High Light Transmittance PC, anti-UV, and Fire Resistant
• LED: Lumileds 2835
• Total Lumens: 14000LM Max.
• Color Temperature: 3000K/4000K/5000K
• Color Rendering index: 70
• Beam Angle: Type V (150 X 150)
• Lifespan: 70000 Hrs.

Applications

• Ideal for gardens, amusement parks, residential areas, industrial parks, and pedestrian streets.

Download PDF File

Specification
