Description

Technical Specs

• Voltage: 120-277V AC 60Hz
• Wattage: 20W-120W
• Power Factor: 0.9
• THD: 20%
• Efficacy: 140 LPW
• Die-Cast Aluminum with Powder Coat Finish
• High Light Transmittance, Anti-UV and Fire Resistant Shatterproof PC Lens
• DC Button Photocell with ON/OFF switch included
• Light Head Can Be Adjusted From 0 to 90 Full Cutoff, Dark Sky Compliant
• Two 1/2š¬šš½ Knockouts on Each Side
• Operating Temperature: -40F -113F
• 7-Year Warranty
• IP65, Suitable For Wet Locations
• Dimming: 0~10V Dimmable
• Multi CCT and Power (Switches are inside fixture)
• Lumileds 2835, High CRI.
• Total Lumens: 16800LM Max
• Color Temperatures: 3000K/4000K/5000K
• Color Rendering Index: CRI 80
• Beam Angle: H127 x V85
• Rated life: 70,000 Hrs

Applications

• Entrance Lighting
• Courtyard Lighting
• Industrial Lighting
• Outdoor Landscape Lighting
• Building The hotel
• Wall Lighting Area And So On

Variations / Specification Sheet

• WAX-20-40W-MCTP – 3000K/4000K/5000K – 20W/30W/40W
• WAX-50-80W-MCTP – 3000K/4000K/5000K 50W/65W/80W
• WAX-90-120W-MCTP – 3000K/4000K/5000K – 90W/105W/120W

Download PDF File

Catalog Page

Specification
