Description

Technical Specs

• Voltage: 120-277V AC 60Hz
• Wattage: 20W
• Power Factor: 0.99
• Efficacy: 80 LPW
• White Finish
• Housing: Die-formed Cold Rolled Steel With Powder Coated White
• Installation: Ceiling-Mounted
• Operating temperature: -22F~104F
• 5-Year Warranty
• Detection Range: 17Ft. / 360
• Mounting Height: 25 Ft. Max.
• DIP Settings switch on The Sensor
• Optional Remote Control (WEC-3RC)
• Output Power: 9W
• Output Voltage: 48V
• Li-Ion Battery / 90 Minutes Emergency Operation
• Test Button Installed on The Side of The Fixture
• Dimming: (Dual Function) Triac Dimmable at 120V 0-10V Dimming at 120-277V
• Lens: Polycarbonate Lens
• Total Lumens: 1600LM
• Color Temperatures: 3000K/4000K/5000K
• Multi-CCT (Selectable switch inside fixture)
• Color Rendering Index: CRI 82
• Life Span: 50,000 hrs.

Applications

• Ideal for a variety of industrial, commercial and residential applications.
