Description

 Technical Specs

• Voltage: 120-277V AC 60Hz
• Wattage: 15W-120W
• Power Factor: 0.9
• THD: 20%
• Efficacy: 130 LPW
• Die-Cast Aluminum with Powder Coat Finish
• High Light Transmittance, Anti-UV and Fire Resistant Shatterproof PC Lens
• DC Button Photocell with On/Off Switch Included
• Two 1/2″ Knockouts on Each Side
• Operating Temperature: -40F -113F
• 7-Year Warranty
• IP65, Suitable for Wet Location
• Dimming: 0-10V Dimmable
• Multi CCT (Switches are inside fixture)
• Lumileds 2835, High CRI
• Total Lumens: 5200LM-15600LM Max.
• Color Temperatures: 3000K/4000K/5000K
• Color Rendering Index: CRI 80
• Beam Angle: H127 x V85
• Rated Life: 70,000 Hrs.

  Applications

• Entrance Lighting
• Courtyard Lighting
• Industrial Lighting
• Outdoor Landscape Lighting
• Building Hotels
• Wall Lighting Areas
